| DOUBLE-LOCK-DEVICES
The
Knee, Arm, Table & Saddle Are Each Equipped With A Pair of Locks To
Firmly Clamp Each Axis And To Eliminate The Possibility of Lateral
Movement. |
|
BACKLASH
ADJUSTMENT
The Double Nut Arrangement Utilized On The Table
And Saddle Allows Backlash To Be Nearly Eliminated And Can Be
Adjusted In A Matter Of Minutes. |
|
PRECISION HAND SCRAPING
The
Upper & Lower Surface Of The Saddle Are Laminated With TURCITE-B And
Precisely Hand Scrapped To Provide A Smooth, Accurate And Wear
Resistant Slideway Surface. |
|
MEEHANITE CAST IRON
All Essential Castings Are Made Of High
Grade Meehanite Cast Iron Which Has Been Stress Relieved To Provide
A Rigid Machine Structure. |
|
LOW VIBRATION VARIOUS SPEED HEAD
The Quietest Head You Ever
Used, With Dynamically Balanced Pulleys And Chrome-Plated Motor
Shaft For Smooth Speed Changing Free Of Noise And Vibration. |
|
SOLID QUILL-FEED
The
Quill-Feed Mechanism Utilizes A One-Piece Pinion Gear And Shaft As
Well As A One-Piece Worm And Wormshaft Both Providing Strength,
Rigidity And Less Maintenance. |
|
HIGH PRECISION SPINDLE
The
Spindle Is Supported By Super Precision Class 7 (P4) Angular Contact
Ball Bearings Which Have Been Accurately Measured, Selected And
Preloaded, Then Assembled In A Temperature Controlled Room To Ensure
Accuracy And Rigidity Throughout The Full RPM Range. |
|
ACCURATELY GROUND QUILL & HOUSING
Hardened And Ground Spindle Back-Gears. The Hard Chromed Quill Is
Ground To Mirror Finish And Fitted To The Quill Housing To Ensure
Smooth Movement, Excellent Rigidity And Offers Extreme High Spindle
Accuracy. |
