RC SERIES
|
|
MADE IN TAIWAN
|
STOCK# |
MODEL |
NET WEIGHT |
| APCG |
RC 12
Centerless Grinder |
3,300 LBS |
| APCG |
RC 16
Centerless Grinder |
4,630 LBS |
| APCG |
RC 18
Centerless Grinder |
5,720 LBS |
| APCG |
RC 1812
Centerless Grinder |
7,055 LBS |
| APCG |
RC 20
Centerless Grinder |
7,700 LBS |
FEATURES: |
MACHINE BED
- The Machine Bed Is Made of High
Quality "MEEHANITE" Cast Iron And Has Aging Treatment. No
Distortion. Machine Bed And Slides Are Also Heat Treatment And
Precision Ground.
|
GEAR BOX
- All Gears Are Made Of SNCM220 Alloy
Steel Having Been Normalized, Carburized Hardened And Precision
Ground. No Vibration & Low Noise.
|
REGULATING WHEEL DRESSING UNIT
- The Angle Of The
Regulating Wheel Dressing Unit Can Be Swiveled According
To Workpiece Requirements In Order To Enhance Accuracy.
|
SERVOMOTOR FOR REGULATING WHEEL
- A Japanese Servo Motor Is Used As
The Regulating Wheel Motor Which Provides Infinitely Variable Speed
Change From 10~250 RPM And Can Be Adjusted To Ideal Linear Speed.
The Servo Motor Is Driven Directly By Worm & Worm Gear. This Can
Reduce Vibration During Grinding And Consequently Achieve The Best
Roundness.
|
UPPER SLIDE
- The Upper Slide Can Be Rapidly And
Precisely Swiveled Up To
± 5 Degree in Order To Grind
Taper In Infeed Grinding And Provide Perfect Contact Between
Workpiece And Grinding Wheel In Thrufeed Grinding.
|
HYDRAULIC DRESSING UNIT
- Both Grinding Wheel And Regulating
Wheel Dressing Units Are Hydraulic Traversed. Traverse Speed Is
Infinitely Adjustable. Dressing Slides Are Made Of Special Allow
Cast Iron And Hand Scraping. Assures Smooth Dressing And High
Accuracy.
|
PRESSURE SWITCH
- One Pressure Switch Is Provided In
The Grinding Wheel Spindle Lubrication System So That The Spindle
Motor Won't Rotate While The Lubrication Pressure Is Reduced. This
Prevents The Spindle From Dry Running And Damages.
|
HYDRAULIC OIL COOLING FAN
- During Grinding, It Cools Down
Hydraulic Oil Temperature And Therefore Reduce Size Vibration. It
Also Enhance Grinding Wheel Spindle Life.
|
